Lumin Non‑Magnetic 35W 24V 600x600 Artificial Skylight LED Panel for MRI Room

LM-PL-MRI-SKY
Lumin's 24V non‑magnetic sky light panel (600x600mm) is crafted from high‑grade aluminum alloy for MRI‑safe environments. Superior build quality with 35W, 600x600mm, CRI>90, 6000K daylight. Ultra‑slim 8.8mm, flicker‑free, ideal for hospitals, MRI rooms, offices, and schools.
minimum order
1 piece
Supply Ability
50000piece / Year
Quantity:
Contact Now

Product Overview：

The Lumin LM‑PL‑66‑35‑Sky is a non‑magnetic LED sky panel light designed specifically for MRI rooms, medical

imaging suites, and other environments sensitive to magnetic interference. Crafted from high‑grade aluminum alloy

(6063) with zero ferromagnetic components, it provides safe, flicker‑free illumination without affecting MRI equipment

performance.

Its 6000K true daylight color temperature and CRI >90 bring outdoor natural light indoors, helping reduce patient

anxiety and improve staff focus. The ultra‑slim 8.8mm profile supports recessed, surface, or suspended mounting –

perfect for clean, modern medical ceilings.

Product Specifications (Model: LM‑PL‑66‑35‑Sky)：

ParameterSpecification
Model No.LM‑PL‑66‑35‑Sky
Output Power35W
Luminous Flux3500 lm (on white background)
Input VoltageDC24V (constant voltage)
Color Temperature (CCT)6000K (daylight / clear sky)
Color Rendering Index (CRI)Ra >90
Dimming Options0‑10V / DALI (customizable)
Installation TypeRecessed / Surface mounted / Suspended
Design Lifetime50,000 hours
MaterialNon‑magnetic aluminum alloy (6063) + PMMA light guide plate + flame‑retardant PC diffuser
IP RatingIP40 (indoor use only)
Dimensions595 × 595 × 8.8 mm
Weight3.3 kg
Warranty3 years limited warranty
CertificationsCE, RoHS, ISO9001 workshop (Lumin China)
Magnetic PropertyFerromagnetic‑free – safe for MRI room


Why Non‑Magnetic for MRI Rooms?

  • No interference with MRI magnetic fields – eliminates image distortion and equipment malfunction risk

  • Aluminum alloy + non‑magnetic components – 100% safe for Zone IV (MRI scanner room)

  • Complies with hospital safety standards for ferromagnetic materials

Important Notices for MRI Installation：

  1. Must use an external DC24V driver approved by Lumin – do not connect directly to AC mains.

  2. Driver must be placed outside the MRI room (in the equipment room or ceiling plenum beyond the 5 Gauss line).

  3. Installation by licensed electrician only – follow MRI suite ferromagnetic safety protocols.

  4. Regular cleaning – power off, use dry soft cloth, no chemical agents.

  5. Warranty void if non‑approved driver is used or the fixture is modified by unlicensed personnel.
